Enphase IQ 5P Battery

The Enphase IQ Battery 5™ all-in-one AC-coupled storage system is powerful, reliable, smart, simple, and safe.  It has a total usable energy capacity of 5 kWh and includes six embedded grid-forming microinverters with 3.84kVA continuous power rating. It provides backup capability and installers can quickly design the right system size to meet the needs of both new and retrofit solar customers.

The Enphase Battery uses a distributed architecture to provide maximum reliability. Each battery includes multiple bi-directional IQ™ 8 microinverters to switch energy from DC to AC and back again for safe, reliable operation. So, even if one stops, the battery will continue to operate and keep the lights on.

IQ Battery 5P system with integrated Enphase IQ Microinverters and battery management system (BMS) with Battery Controller, includes:

  • IQ Battery 5P unit (B05-T02-ROW00-1-2)
  • IQ Battery 5P cover and wall-mount bracket (B05-CX-0550-O; B05-WB-0543-O)
  • IQ Battery 5P uses a third-generation storage technology and doesn’t have any moving parts that can break over time.

Key features and benefits of Enphase IQ Battery

Powerful

• Provides 3.84 kVA continuous and 7.68 kVA peak power

• Includes six embedded IQ8D-BAT Microinverters

Reliable

  • 15-year limited warranty
  • Passive cooling (no moving parts/fans)
  • Uses wired communication for fast and consistent connection
  • Updates software and firmware remotely

Read and download the Enphase Preliminary Data Sheet Compendium, which includes technical information about the IQ Battery 5P, the IQ System Controller 3 INT, and the IQ8 Series Microinverters.

Order Yours Today!

Smart

  • Grid-forming capability for backup operation
  • Remote software and firmware upgrade
  • Mobile app-based monitoring and control
  • Support for self consumption
  • Utility time of use (TOU) optimization

Simple

  • Fully integrated AC battery system
  • Installs and commissions easily
  • Supports backup, self-consumption, and time of use (TOU) modes.
  • Quick and easy plug-and-play installation
  • Interconnects with standard household AC wiring
  • Offers homeowners remote monitoring and control from the Enphase App
  • Field replaceable components

Safe

  • Battery safety tested to meet UL 9540A, the highest industry standard for battery safety
  •  Uses lithium iron phosphate (LFP) chemistry for maximum safety and longevity

Enphase IQ Battery 5 Specifications

Output (AC) @ 240Vac

Rated (continuous) output power 3.98kVA

Peak output power  7.68kVA (3 seconds), 6.14kVA (10 seconds)

Battery

Total Capacity 5kWh

Usable Capacity 4.96kWh

Round Trip Efficiency 96%

Ambient operating temperature -20C to 55C non -condensing

Optimum operating temperature range. 0C to 30C

Chemistry Lithium iron phosphate (LFP)
